Product advantages:
1. Precise control, with multiple functions such as pressure control and displacement control.
2. Four-column floor structure, adopts four-column structure design, uniform and stable force, ensuring parallelism and accuracy during press-fitting.
3. Easy to operate, the equipment adopts touch screen and button operation interface.
4. Safe and reliable, with fault alarm and protection functions.
Application field:
Four-column press-fitting equipment is widely used in precision press-fitting operations in the automotive, electronics, machinery, hardware and other industries. Whether it is the assembly of parts, the pressing of molds or other press-fitting operations that require precise control, the equipment can provide stable, efficient and precise solutions.

Technical Parameters
Series Model: PDSP-G01
Rated pressure	kN	10	20	30	50
Mode Selection	Pressure mode/position mode
Maximum speed	mm/s	250	125	125	125
Repeatability	mm	0.01
Stroke length	mm	250	250	250	250
Pressure accuracy	±0.5%F.S
Rated Power	kW	2.5	2.5	3	5
Supply voltage	V	Three-phase AC380V	Three-phase AC380V	Three-phase AC380V	Three-phase AC380V
Features	1. High-precision pressure control system; 2. Expandable full-closed-loop grating ruler
